Toro Aerator 687 Tow Behind Corer

Toro
Model: 02255e1d9aa3

The 687 Turf Aerator is an effective and efficient way to aerate your large turf areas. Designed with 70 pound (32 kg) cast wheels and a unique floating head design, this aerator provides excellent depth performance and follow ground contours, vertically and horizontally, like no other aerator available. For highly compacted or unusually uneven grounds, optional rear weights are available.

  • Drop pin, tow type with optional hydraulic lift (686) or 3-point, Category 1 mount (687)
  • Three independent coring heads for exceptional ground following.
  • Solid and coring tines deliver the exact aeration needed.
  • 78″ (1.98 m) aeration swath and up to 10 mph (16 km/h) provides the ultimate productivity.
Fleet Finance & Leasing Options
Talk to us today 0800 807 333
Call 0800 807 333
Talk to a rep

Attach & Go

Drop pin, tow type with optional hydraulic lift (686) or 3-point, Category 1 mount (687)

Fast and Productive

78" (1.98 m) aeration swath and up to 10 mph (16 km/h) provides the ultimate productivity.

Tines to Match Your Need

Solid and coring tines deliver the exact aeration needed.

Contour Following

Three independent coring heads for exceptional ground following.

Specifications

Aeration Type Shallow
Cast Wheels 3 sets of 4, each set moves independently. 70 lbs. (32 kg), 13" (33 cm) diameter.
Forward Hole Spacing 6" (15 cm)
Height approx. 40" (102 cm)
Hitch 3-point Category 1 hitch.
Lateral Hole Spacing 3" (8 cm)
Length 48" (122 cm)
Operating Speed 1 - 10 mph (1.6 - 16.1 km/h)
Operating Width (Working Width) 78" (198 cm)
Show all Specifications

Brochures, Parts & Manuals

Toro Aerator 686 / 687 Turf Aerator Tow Behind Spec Sheet

Download | View

2023-24 Toro Performance Parts Quick Reference Guide (Full Brochure)

Download | View

Toro® TITAN® Tine – Reference Chart

Download | View

2023-2024 Toro® TITAN® Tines – Brochure

Download | View
